Item number

YG008A

YG008B

YG008C

Cut Hole

3‘‘

4‘‘

6‘‘

Type IC

YES

YES

YES

Shape

Round/Square

Round/Square

Round/Square

WET Locations

YES

YES

YES

Air Tight

YES

YES

YES

Finish

White/Black/Brush Nickel

White/Black/Brush Nickel

White/Black/Brush Nickel

Color (CCT)

3000K,4000K,5000K Selectable

3000K,4000K,5000K Selectable

3000K,4000K,5000K Selectable

Lumen

500LM

750LM

1000LM

CRI

>80

>80

>80

Power(Wattage)

5W

9W

12W

Input Volts

AC120V

AC120V

AC120V

Rated Lifetime

50,000hrs

50,000hrs

50,000hrs

Dimmable

Triac Dimming

Triac Dimming

Triac Dimming

Power Factor

0.97

0.97

0.97

IP Range

IP44

IP44

IP44

Frequency

60HZ

60HZ

60HZ

Lumen Efficacy

95LM/W

84LM/W

84LM/W

Operating Temp:

-40℃ _ 40℃

-40℃ _ 40℃

-40℃ _ 40℃

Driver Type

Class II

Class II

Class II

Warranty

5 Years

5 Years

5 Years
