Watt

Shape

Lumen

CCT

Size

Series

14

Square

85lm/w

3CCT

5-1/2"*3-1/8"*H3-3/8”Cut Hole: 4-3/4"*2-3/8”

YG032A

20

Square

85lm/w

3CCT

7-1/8"*3-5/8"*H4-3/8”Cut Hole: 6-1/2"*3-1/8”

YG032A

40

Square

85lm/w

3CCT

8-3/4"*4-3/8"*H5-1/4”Cut Hole: 8-1/4"*3-3/4”

YG032A

14

Square

85lm/w

3CCT

5-1/8"*2-3/4"*H3-3/8”Cut Hole: :4-3/4"*2-3/8”

YG032B

40

Square

85lm/w

3CCT

7-1/8"*3-5/8"*H4-3/8”Cut Hole: 6-1/2"*3-1/8”

YG032B

60

Square

85lm/w

3CCT

8-3/4"*4-3/8"*H5-1/4”Cut Hole: 8-1/4"*3-3/4”

YG032B

14

Square

85lm/w

3CCT

5-1/8"*2-3/4"*H3-5/8”Cut Hole: 4-3/4"*2-3/8”

YG032C

20

Square

85lm/w

3CCT

7"*3-1/2"*H4-5/8” Cut Hole: 6-1/2"*3-1/8”

YG032C

40

Square

85lm/w

3CCT

7-3/4"*4-1/8"*H5-5/8”Cut Hole: 7-1/2"*3-3/4”

YG032C

Color(Temp)

CCT Selectable

Color(CCT)

3000K/4000K/5000K

Lumen

85lm/W

Input Volts

AC120V-277V

Dimmable

Non-dimmable;Traic/0-10v/1-10v/Dali dimmable

Light Source

COB

LED Brand

OSRAM

Construction

Aluminum

Operation Temp

 -20-+40D

Mounting

Recessed

IP Range

IP65

Beam Angle

8°/10°/15°/24°/38°/50°/60°

Service Lifetime

50,000Hrs

PF

≥0.90

UGR

<13
